EN 10028-4 15NiMn6 Steel Plate | 15NiMn6 Ni-Mn Low Temp Vessel Plate

15NiMn6 is the higher Ni-Mn step in the low-nickel end of EN 10028-4. Buyers search EN 10028-4 15NiMn6, 15NiMn6 steel plate, 1.6228, 15NiMn6 Ni-Mn low temp vessel plate and 15NiMn6 supplier. Nickel is about 1.20–1.70%. Manganese is about 0.80–1.50%. This is not 11MnNi5-3. That grade is 0.5Ni. This is not 13MnNi6-3. That grade is 0.75Ni. This is not 12Ni14. 12Ni14 is 3.5Ni. This is not X8Ni9. X8Ni9 is 9Ni.

Yield is in the 390 MPa class at the usual thin-plate column. Tensile is 530–710 MPa. Steel number is 1.6228. Delivery is usually normalized (+N). Charpy is specified at −80 °C when the order follows this grade. SHH STEEL is a global steel mill sourcing partner and steel manufacturer & exporter (mill-direct, China origin). We buy this grade from qualified Chinese mills, check the certificate against EN 10028-4, and ship it to fabricators in the USA, Europe, Middle East, Southeast Asia, Africa and South America.

Do not ship 13MnNi6-3 against a 15NiMn6 drawing and call 0.75Ni close to 1.5Ni. Do not ship 15MnNiNbDR steel plate and call the names identical unless both books are met. Do not ship SA203 Grade A. That grade is 2.25Ni. Dual marking is possible only when chemistry, tensile, impact temperature and delivery all fit.

Company scope: global exporter SHH STEEL.

This plate sits in pressure vessel steel plates. Chinese Mn-Ni comparisons belong on GB/T 713.3. 3.5Ni / 9Ni comparisons belong on GB/T 713.4 and ASME SA-203.

EN 10028-4 15NiMn6 Steel Plate | 15NiMn6 Ni-Mn Low Temp Vessel Plate

Brief Description
EN 10028-4 15NiMn6 is European Ni-Mn low-temperature vessel plate, steel number 1.6228. Yield is 390 MPa class. Impact is −80 °C. SHH STEEL supplies 15NiMn6 worldwide as a global steel mill sourcing partner.

SEO Title
EN 10028-4 15NiMn6 Steel Plate | 15NiMn6 Ni-Mn Low Temp Vessel Plate – SHH STEEL

SEO Keywords
EN 10028-4 15NiMn6, 15NiMn6, 15NiMn6 steel plate, 1.6228, 15NiMn6 Ni-Mn vessel plate, 15NiMn6 equivalent, 15NiMn6 supplier

SEO Description
SHH STEEL supplies EN 10028-4 15NiMn6 Ni-Mn low-temp vessel plate worldwide, 390 MPa yield class, −80 °C impact, steel number 1.6228. EN 10204 3.1/3.2 mill-direct supply. Contact now.

General Description

15NiMn6 is the higher Ni-Mn step in the low-nickel end of EN 10028-4. Buyers search EN 10028-4 15NiMn6, 15NiMn6 steel plate, 1.6228, 15NiMn6 Ni-Mn low temp vessel plate and 15NiMn6 supplier. Nickel is about 1.20–1.70%. Manganese is about 0.80–1.50%. This is not 11MnNi5-3. That grade is 0.5Ni. This is not 13MnNi6-3. That grade is 0.75Ni. This is not 12Ni14. 12Ni14 is 3.5Ni. This is not X8Ni9. X8Ni9 is 9Ni.

Yield is in the 390 MPa class at the usual thin-plate column. Tensile is 530–710 MPa. Steel number is 1.6228. Delivery is usually normalized (+N). Charpy is specified at −80 °C when the order follows this grade. SHH STEEL is a global steel mill sourcing partner and steel manufacturer & exporter (mill-direct, China origin). We buy this grade from qualified Chinese mills, check the certificate against EN 10028-4, and ship it to fabricators in the USA, Europe, Middle East, Southeast Asia, Africa and South America.

Do not ship 13MnNi6-3 against a 15NiMn6 drawing and call 0.75Ni close to 1.5Ni. Do not ship 15MnNiNbDR steel plate and call the names identical unless both books are met. Do not ship SA203 Grade A. That grade is 2.25Ni. Dual marking is possible only when chemistry, tensile, impact temperature and delivery all fit.

Company scope: global exporter SHH STEEL.

Material Specification

This plate sits in pressure vessel steel plates. Chinese Mn-Ni comparisons belong on GB/T 713.3. 3.5Ni / 9Ni comparisons belong on GB/T 713.4 and ASME SA-203.

Chemical Composition

Cast analysis follows EN 10028-4. Product analysis follows EN 10028-1 when ordered. People who search 15NiMn6 chemical composition and 1.6228 chemistry want nickel and manganese on the certificate, not a 13MnNi6-3 table copied across.

Cast Analysis and Product Analysis — EN 10028-4 15NiMn6 (1.6228)

Nickel at 1.20–1.70% is the grade marker. That is still a Ni-Mn plate, not 3.5Ni and not 9Ni. Carbon stays limited because toughness at −80 °C is the job. SHH STEEL prints heat analysis on every certificate and product analysis when ordered. Density is 7.85 g/cm³.

Buyers search 15NiMn6 mechanical properties, 15NiMn6 yield strength and 15NiMn6 impact. Yield falls as thickness rises.

Tensile and Yield — EN 10028-4 15NiMn6

Elongation is typically 20% min on thinner plate. Charpy for this grade is −80 °C. Energy is commonly 27 J average when the order follows the book. Location and orientation must be written. Do not assume −60 °C from 11MnNi5-3 is enough. Do not assume −100 °C. That is 3.5Ni.

Do not quote 390 MPa yield on an 80 mm plate. Do not treat −80 °C as permission to stamp 15MnNiNbDR steel plate or SA203 Grade A without checking both books.

Buyers pick 15NiMn6 when a PED file wants more nickel than 13MnNi6-3 and a 390 MPa step, without jumping to 3.5Ni. Search phrases such as 15NiMn6 boiler plate, 1.6228 steel plate and 15NiMn6 Ni-Mn vessel plate all point here.

It is not a substitute for 08Ni3DR steel plate. That grade is 3.5Ni around −100 °C. It is not a substitute for 06Ni9DR steel plate. That grade is 9Ni −196 °C. It is not LNG inner-tank plate.

An ASME file that wants nickel vessel plate should name SA-203 on ASME SA203 and then write the grade. Dual marking is possible only when both books are met. SHH STEEL supplies this plate to fabricators in the United States, Mexico, South America, Europe, the Middle East, Africa and Asia.

15NiMn6 is Ni-Mn vessel plate at about 1.5% nickel. Treat welding as production welding, and as PED / ASME Code welding when the equipment is a vessel.

Qualify to the applicable code. Consumables must keep toughness at −80 °C. A carbon procedure written for SA516 Grade 70 is not automatically valid. A 0.75Ni procedure written for 13MnNi6-3 is the previous family. A 3.5Ni procedure written for SA203 Grade D is the next family. The fabricator owns the WPS. SHH STEEL can share mill heat data for that review.

Usual delivery from SHH STEEL is normalized EN 10028-4 15NiMn6 (+N).

If the vessel will see PWHT, say so. Impact after simulated PWHT is worth naming on a −80 °C file. Extra simulation, 3.2 hold points or special NDE add time. Plan about two months when those extras are on the order.

The certificate lists EN 10028-4 15NiMn6; 1.6228; heat number; cast analysis including nickel and manganese; product analysis when ordered; tensile to the correct thickness column; +N; Charpy at −80 °C when ordered. Certificates may be EN 10204 3.1 or EN 10204 3.2.

Usual supply range from SHH STEEL for 15NiMn6 Ni-Mn low temp vessel plate:

• Thickness: commonly 6 mm – 120 mm, thicker by mill agreement
• Width: 1500 mm – 4000 mm
• Length: 3000 mm – 12000 mm

0.5Ni plate is 11MnNi5-3. 0.75Ni plate is 13MnNi6-3. 3.5Ni plate belongs on 08Ni3DR steel plate. 9Ni plate belongs on 06Ni9DR steel plate.

Dimensional limits follow EN 10028-1 and EN 10029 unless the order names another table. Class A is the usual default. If the calculation used minimum thickness after corrosion, write the allowed minus. Do not apply ASTM A36 structural tolerances to a PED −80 °C Ni-Mn plate without writing them.

Charpy details. Write −80 °C, joules, location and orientation.

Impact after simulated PWHT. When the vessel will be stress-relieved.

Product analysis. Especially nickel, manganese, P, S and Al.

NDE. EN 10160 or ASTM A435 / A578 as named.

Third-party. EN 10204 3.2 when written.

15NiMn6 is the plate for a PED file that wants more nickel than 13MnNi6-3 and a 390 MPa step, without paying 3.5Ni or 9Ni. It is the wrong plate for LNG inner tanks. That work belongs on 06Ni9DR steel plate.

SHH STEEL sources EN 10028-4 15NiMn6 from first-line Chinese mills and ships it on worldwide terms. Partner mills include Wuyang (Wugang), Angang, Shougang, Hanye, Anyang Iron & Steel, Baosteel, Xinyu, Xingcheng, Yongjin, Tsingshan, TISCO (Taiyuan), Jiuquan (JISCO), Lianzhong, Zhangpu and Baoxin, plus other qualified mills when the size or normalizing route requires it.

Mill test certificates are issued to EN 10204 3.1 as standard. EN 10204 3.2 is arranged when the order names a third-party hold point.

Usual stock and rolling thickness: 8 mm, 10 mm, 12 mm, 16 mm, 20 mm, 25 mm, 30 mm, 32 mm, 36 mm, 40 mm, 50 mm, 60 mm, 80 mm, 100 mm, thicker by mill agreement.

Processing: CNC or flame cutting, bevel, flattening, UT to EN 10160 or the named class.

Trade terms: FOB Shanghai main, CIF destination available. Payment: TT, LC, or TT + LC.

Ocean time from Shanghai: US West 14–18 days; US Gulf 28–35 days; Rotterdam / Antwerp 28–35 days; Jebel Ali 18–25 days; Singapore 7–12 days; other ports quoted.

Third-party: SGS, TÜV, BV, ABS, CCS, GL, VL, DNV, RINA, NK, KR, or the inspector named.

SHH STEEL is a global steel mill sourcing partner with mill partnerships in China. We supply ASTM, ASME, EN, DIN, JIS and GB steel to buyers in the United States, Europe, the Middle East, Southeast Asia, Africa and South America. Origin is mill-direct, China origin.

SHH STEEL has supplied steel plates to the USA, Mexico, Argentina, Peru, El Salvador, Spain, Netherlands, Germany, UAE, Saudi Arabia, South Africa, India, Thailand, Singapore, Vietnam, the Philippines, Japan and Korea.

Typical lead time: ex-stock 5–7 days; standard +N about 45 days; simulated PWHT / 3.2 about 2 months.

Company scope: worldwide delivery SHH STEEL.

Experience on this grade is simple: Ni-Mn chemistry and −80 °C must both be on the certificate. SHH STEEL as a global steel mill sourcing partner and steel manufacturer & exporter (mill-direct, China origin) prices 15NiMn6 from first-line mills, reports 1.6228 chemistry including nickel, records +N, prints Charpy at −80 °C when ordered, and issues 3.1 as standard or 3.2 when specified.

We keep the grade on the order. 15NiMn6 is not 13MnNi6-3. 15NiMn6 is not 12Ni14. 15NiMn6 is not X8Ni9. 15NiMn6 is not Q345R steel plate. If the drawing says 3.5Ni, we will not ship 1.5Ni and call nickel close.

Company scope: global exporter SHH STEEL.

EN 10028-4 15NiMn6 Steel Plate is European Ni-Mn low-temperature pressure-vessel plate, steel number 1.6228, at the 390 MPa yield class and 530–710 MPa tensile, usually +N, with Charpy at −80 °C when ordered. Whether the inquiry says EN 10028-4 15NiMn6, 1.6228 or 15NiMn6 Ni-Mn Low Temp Vessel Plate, SHH STEEL as a global steel mill sourcing partner and steel manufacturer & exporter (mill-direct, China origin) supplies plate with 15NiMn6 chemistry, recorded +N, and EN 10204 3.1 or 3.2 certification.

SHH STEEL supplies EN 10028-4 15NiMn6 Ni-Mn Low Temp Vessel Plate to the USA, Mexico, South America, Europe, the Middle East, Africa and Asia for work that actually names this grade.

Contact SHH STEEL for mill rolling, stock inquiry, cutting, bevel, 3.2 inspection or a worldwide quotation.
