EN 10028-2 7CrMoVTiB10-10 Steel Plate | T24 2.25Cr-Mo-V-Ti-B Vessel Plate

7CrMoVTiB10-10 is the titanium-boron 2.25Cr-Mo-V grade in EN 10028-2. Buyers almost never type the full EN name first. They type T24, T24 steel plate, 7CrMoVTiB10-10, 1.7378 and T24 2.25Cr-Mo-V-Ti-B vessel plate. All of those names belong on this page. T24 is the market / tube-family name. 7CrMoVTiB10-10 is the EN steel name. 1.7378 is the steel number.

This is not 10CrMo9-10. 10CrMo9-10 is 2.25Cr-1Mo without vanadium, titanium and boron. This is not P91. P91 is 9Cr-1Mo-V-Nb. This is not T23. T23 is a different tungsten-vanadium family. Chromium stays in the 2.20–2.60% band. Molybdenum stays near 1%. Vanadium, titanium and boron are mandatory. That package is why T24 was developed for high-temperature water-wall and header work, and why welding cannot be copied from a Grade 22 procedure.

Yield on the EN plate table is in the 450 MPa class at the usual thin-plate column. Tensile is 580–760 MPa. Tube product T24 often sits at a higher yield in ASME SA-213. Plate and tube are not automatic twins. Dual marking is possible only when both books are fully met. Delivery is usually normalized and tempered. Write the route. SHH STEEL is a global steel mill sourcing partner and steel manufacturer & exporter (mill-direct, China origin) supplying this grade to the USA, Europe, Middle East, Southeast Asia, Africa and South America.

Do not ship SA387 Grade 22 Class 2 against a T24 drawing. Grade 22 has no Ti-B-V set of this type. Do not ship SA387 Grade 91 Class 2 and call 9Cr better. The ASME talk grades around this chemistry are SA832 Grade 22V and SA542 Type C Class 4. Dual marking is possible only when chemistry, tensile, hardness, impact and heat treatment all fit.

Company scope: global exporter SHH STEEL.

This plate sits in pressure vessel steel plates. 2.25Cr-1Mo comparisons belong on ASME SA387. Cr-Mo-V comparisons belong on ASME SA832 and ASME SA542.

Cast analysis follows EN 10028-2 Table 1. Product analysis follows EN 10028-1 when ordered. People who search T24 chemical composition, 7CrMoVTiB10-10 chemistry and 1.7378 composition want titanium and boron on the certificate, not only chromium and molybdenum.

Cast Analysis and Product Analysis — EN 10028-2 7CrMoVTiB10-10 (1.7378)

Carbon is low on purpose. Titanium and boron are the grade. Nitrogen and aluminum stay limited because they fight the titanium-boron effect. If a mill certificate shows 2.25Cr-1Mo and no Ti-B-V, that plate is 10CrMo9-10, not T24. SHH STEEL reports cast analysis on every certificate and product analysis when ordered. Density is 7.85 g/cm³.

Buyers search T24 mechanical properties, 7CrMoVTiB10-10 yield strength and T24 tensile strength. EN plate values and ASME T24 tube values sit in the same family. They are not copy-paste identical. Write the product form.

Tensile and Yield — EN 10028-2 7CrMoVTiB10-10 / T24 plate

Impact at 0 °C, 27 J, is the usual option when the order names it. Hardness after heat treatment matters because T24 can run hard if tempering is short. Elevated-temperature proof strength is why the grade exists. Ask for that table when the vessel calculation uses design temperature.

Do not quote 450 MPa yield on every thickness. Do not treat 580–760 MPa tensile as permission to stamp SA387 Grade 22 Class 2 or SA832 Grade 22V without checking both books.

Search habits mix T24 equivalent, 7CrMoVTiB10-10 equivalent, 1.7378 equivalent and T24 vs T23. Those names help a buyer find the right page. They do not authorize substitution.

Buyers pick 7CrMoVTiB10-10 / T24 when the file wants 2.25Cr-1Mo with vanadium, titanium and boron for higher-temperature water-wall, collector and thin-wall high-temp service. Search phrases such as T24 boiler plate, T24 pressure vessel plate, 7CrMoVTiB10-10 steel plate and 1.7378 steel plate all point here.

T24 exists because Grade 22 runs out of strength in some high-temperature thin-wall designs. That does not mean T24 replaces every Grade 22 file. A hydroprocessing vessel written to SA387 Grade 22 Class 2 still wants Grade 22 unless the designer changes the book. A 9Cr file written to SA387 Grade 91 Class 2 is a different family.

SHH STEEL supplies this plate to fabricators in the United States, Mexico, South America, Europe, the Middle East, Africa and Asia. The purchase is not limited to China, Hong Kong or Singapore.

7CrMoVTiB10-10 / T24 is not a Grade 22 weld. Treat welding as production welding, and as PED / ASME Code welding when the equipment is a vessel.

Qualify to the applicable code. ASME dual-name work uses ASME Section IX. Consumables must be T24-matching consumables, not Grade 22 and not P91. Preheat, hydrogen control and the PWHT window belong in the procedure. T24 has a reputation in the industry for heat-affected-zone sensitivity when the procedure is copied from Grade 22. That is a qualification issue, not a warehouse issue. The fabricator owns the WPS. SHH STEEL can share mill heat data for that review.

Usual delivery from SHH STEEL is normalized and tempered EN 10028-2 7CrMoVTiB10-10. Buyers who search T24 heat treatment, T24 PWHT or 7CrMoVTiB10-10 NT are asking for this control.

If the vessel will see PWHT, write the temperature window. Test coupons then follow a simulated cycle. Hardness after simulated PWHT is worth naming on this grade. Extra simulation, 3.2 hold points or special NDE add time. Plan about two months when those extras are on the order.

The certificate lists EN 10028-2 7CrMoVTiB10-10; T24 when the order uses that name; 1.7378; heat number; cast analysis including V, Ti and B; product analysis when ordered; tensile to the correct thickness column; +NT; hardness when ordered; impact when ordered; elevated-temperature values when ordered. Certificates may be EN 10204 3.1 or EN 10204 3.2.

Usual supply range from SHH STEEL for T24 2.25Cr-Mo-V-Ti-B vessel plate:

• Thickness: commonly 6 mm – 80 mm, thicker by mill agreement
• Width: 1500 mm – 3000 mm
• Length: 3000 mm – 12000 mm

Plain 2.25Cr-1Mo belongs on 12Cr2Mo1R steel plate. 1Cr-0.5Mo belongs on 15CrMoR steel plate. Carbon vessel plate belongs on Q345R steel plate.

Dimensional limits follow EN 10028-1 and EN 10029 unless the order names another tolerance table. Do not apply ASTM A36 structural tolerances to a PED T24 vessel plate without writing them.

Charpy details. Temperature, energy, location and orientation.

Hardness. After heat treatment and after simulated PWHT when written.

Product analysis. Add this when the destination file wants finished-plate chemistry, especially Ti, B and V.

Elevated-temperature proof strength. Add this when the calculation uses design temperature.

Simulated PWHT. Almost always relevant on T24 equipment.

NDE. EN 10160 or the named UT class.

Third-party. EN 10204 3.2 when written.

SHH STEEL sources EN 10028-2 7CrMoVTiB10-10 / T24 from first-line Chinese mills and ships it on worldwide terms. Partner mills include Wuyang (Wugang), Angang, Shougang, Hanye, Anyang Iron & Steel, Baosteel, Xinyu, Xingcheng, Yongjin, Tsingshan, TISCO (Taiyuan), Jiuquan (JISCO), Lianzhong, Zhangpu and Baoxin, plus other qualified mills when the size or heat-treatment route requires it.

Mill test certificates are issued to EN 10204 3.1 as standard. EN 10204 3.2 is arranged when the order names a third-party hold point.

Usual stock and rolling thickness for this family: 8 mm, 10 mm, 12 mm, 16 mm, 20 mm, 25 mm, 30 mm, 32 mm, 36 mm, 40 mm, 50 mm, 60 mm, 80 mm, with thicker plate by mill agreement. Width and length follow the mill table above.

Processing available with the plate: CNC or flame cutting to drawing, bevel preparation, flattening, and ultrasonic testing to EN 10160 or the named class. Extra NDE is written on the order, not assumed.

Trade terms: FOB Shanghai is the usual main term. CIF to the buyer’s destination port can be quoted. Payment is TT, LC, or TT + LC, as agreed on the contract.

Destination ports and typical ocean time from Shanghai, subject to sailing and customs:

• US West Coast (Los Angeles / Long Beach / Oakland): about 14–18 days
• US Gulf (Houston / New Orleans): about 28–35 days
• Rotterdam / Antwerp: about 28–35 days
• Jebel Ali: about 18–25 days
• Singapore: about 7–12 days
• Other major ports in Mexico, South America, the Mediterranean, India, Africa, Japan and Korea: quoted case by case

Third-party inspection can be SGS, TÜV, BV, ABS, CCS, GL, VL, DNV, RINA, NK, KR, or the inspector the buyer names. The hold point is booked before rolling or before shipment, depending on the 3.2 scope.

SHH STEEL is a global steel mill sourcing partner with mill partnerships in China. We supply ASTM, ASME, EN, DIN, JIS and GB steel to buyers in the United States, Europe, the Middle East, Southeast Asia, Africa and South America. Origin is mill-direct, China origin. The commercial offer is not limited to one region.

SHH STEEL has supplied steel plates to the USA, Mexico, Argentina, Peru, El Salvador, Spain, Netherlands, Germany, UAE, Saudi Arabia, South Africa, India, Thailand, Singapore, Vietnam, the Philippines, Japan and Korea.

Typical lead time:

• Ex-stock: about 5–7 days when T24 plate is in yard
• Mill rolling, standard +NT: about 45 days
• Simulated PWHT, hardness, 3.2 or extra NDE: about 2 months

Company scope: worldwide delivery SHH STEEL.

SHH STEEL is a global steel mill sourcing partner and steel manufacturer & exporter (mill-direct, China origin). On EN 10028-2 7CrMoVTiB10-10 / T24 that means mill pricing from Wuyang, Angang, Baosteel and other first-line mills, 1.7378 chemistry with V-Ti-B reported, product analysis when ordered, recorded +NT, tensile to the correct thickness column, 3.1 as standard and 3.2 when specified.

We keep the grade on the order. T24 is not 10CrMo9-10. T24 is not SA387 Grade 22 Class 2. T24 is not P91. T24 is not Q345R steel plate. If the drawing says Grade 22, we will not ship T24 and call titanium better.

Company scope: global exporter SHH STEEL.

EN 10028-2 7CrMoVTiB10-10 Steel Plate is European 2.25Cr-Mo-V-Ti-B high-temperature pressure-vessel plate, steel number 1.7378, market name T24, at the 450 MPa yield class and 580–760 MPa tensile, usually +NT. Whether the inquiry says EN 10028-2 7CrMoVTiB10-10, 1.7378, T24 steel plate or T24 2.25Cr-Mo-V-Ti-B Vessel Plate, SHH STEEL as a global steel mill sourcing partner and steel manufacturer & exporter (mill-direct, China origin) supplies plate with T24 chemistry, heat and product analysis when ordered, recorded +NT, and EN 10204 3.1 or 3.2 certification.

SHH STEEL supplies EN 10028-2 7CrMoVTiB10-10 T24 2.25Cr-Mo-V-Ti-B Vessel Plate to the USA, Mexico, South America, Europe, the Middle East, Africa and Asia for work that actually names this grade.

Contact SHH STEEL for mill rolling, stock inquiry, cutting, bevel, 3.2 inspection or a worldwide quotation.
