ASTM A514 Grade P Steel Plate | A514 Gr.P 100ksi QT Structural Plate supplier

ASTM A514 Grade P, also searched as A514 Gr.P, A514GRP, A514-P, A514P, T-1 Grade P and 100 ksi QT plate, is the nickel-chromium-molybdenum thick-plate grade in ASTM A514/A514M. That book covers quenched-and-tempered alloy structural plates intended primarily for welded bridges and other structures. Maximum thickness for Grade P is 6 in / 150 mm. General requirements follow ASTM A6 / ASME SA-6, not A20 / SA-20.

There is no ASME SA-514 / SA-514M book in current Section II, Part A. Inquiries that write SA514 Gr.P are still buying ASTM A514 Grade P. Code quenched-and-tempered vessel plate is ASTM A517 Grade P, not A514.

This page is not Grade Q. Grade Q also goes to 150 mm, but Grade Q requires vanadium and a different chromium band. This page is not Grade E. Grade E uses 1.40–2.00% Cr and no nickel. This page is not Grade B, Grade F, Grade H or Grade S. Those grades stop at 32–65 mm. This page is not A572 Gr.50. This page is not EN 10025-6 S690QL. This page is not GB/T 16270 Q690E. Q690E is a Chinese QT comparison, not an automatic A514 certificate.

To 2½ in / 65 mm, yield is 100 ksi / 690 MPa min and tensile is 110–130 ksi / 760–895 MPa. Over 2½ in to 6 in / 65–150 mm, yield drops to 90 ksi / 620 MPa min and tensile is 100–130 ksi / 690–895 MPa. Delivery is quenched and tempered. Grade P chemistry carries 1.20–1.50% nickel, 0.85–1.20% chromium, molybdenum and boron.

SHH STEEL is a global steel mill sourcing partner and steel manufacturer & exporter (mill-direct, China origin). We buy this grade from qualified Chinese mills, print heat analysis and product analysis when ordered, record QT on the certificate, and ship plate to fabricators in the USA, Europe, Middle East, Southeast Asia, Africa and South America.

Related category pages: structural steel plates, ASTM A572 / A572M and EN 10025-6.

Other 150 mm A514 sisters are Grade Q and Grade E. QT vessel sisters belong on ASTM A517 Grade P. European 690 MPa QT sisters belong on EN 10025-6 S690Q and EN 10025-6 S690QL.

Grade P is the Ni-Cr-Mo-B member that can go to 150 mm. Vanadium is not required on Grade P. Heat analysis is the mill table. Product analysis, when ordered, follows ASTM A6 / SA-6 product-analysis tolerances.

Heat Analysis and Product Analysis — ASTM A514 Grade P

Grade Q uses 1.00–1.50% Cr plus 0.03–0.08% V. Grade E uses 1.40–2.00% Cr and no nickel. Grade S uses high manganese and niobium with no nickel or chromium. Do not accept a Q heat on a Grade P order just because both go to 150 mm. If product analysis is on the purchase order, SHH STEEL prints both columns on the certificate. Density is 7.85 g/cm³.

Buyers search A514 Gr.P mechanical properties, A514GRP yield, A514 P 100 ksi and T-1 Grade P tensile.

Tensile, Yield and Hardness — ASTM A514 Grade P

Do not quote 690 MPa yield on an 80 mm plate. Over 65 mm the book already drops to 620 MPa. Grade B, Grade F, Grade H and Grade S cannot use this third row.

A572 Gr.50 is 345 MPa yield. ASTM A36 steel plate is 250 MPa yield. Neither is A514.

There is no official one-to-one worldwide swap for A514 Gr.P. What buyers compare is the 690 MPa QT structural idea up to 150 mm.

In the United States the official plate name is ASTM A514 Grade P. Market shops still say T-1. T-1 is a product name, not the ASTM grade. ASTM A517 Grade P is the vessel QT cousin under A20. Do not dual-mark A514 as A517 unless both books are fully met.

In Europe the usual comparison is EN 10025-6 S690Q or EN 10025-6 S690QL. See EN 10025-6. Dual marking only when both books are met.

In China the nearest QT comparison is GB/T 16270 Q690D / Q690E. That book is high-yield quenched-and-tempered structural plate. Q690E adds a −40 °C impact table. GB/T 1591 Q690C / Q690D / Q690E is a different book and is not automatically QT A514. GB chemistry does not copy the Grade P nickel-chromium window. Dual marking only when both books are fully met. Do not treat Q345B or Q355B as A514.

Buyers pick A514 Gr.P when a boom, mining chassis or bridge member wants 100 ksi yield, nickel-chromium chemistry, and plate up to 150 mm. Search phrases such as A514GRP, A514 Grade P, A514-P, T-1 Grade P and Q690E all point here when the file is actually A514.

It is the wrong plate for a file that named Grade Q vanadium chemistry. That work is Grade Q. It is the wrong plate for a Section VIII vessel that names SA-517. That work is ASTM A517 Grade P. It is the wrong plate for a 345 MPa frame that names A572 Gr.50.

SHH STEEL supplies this plate to fabricators in the United States, Mexico, South America, Europe, the Middle East, Africa and Asia.

A514 Grade P is killed QT alloy structural plate at 690 MPa yield with 1.20–1.50% nickel. Treat welding as production welding. Heat input, preheat and interpass have to stay inside a written WPS.

Qualify to the applicable structural code. Consumables must match a 100 ksi QT family. A procedure written for Grade S may not cover the nickel-chromium window. A procedure written for A572 Gr.50 is 345 MPa HSLA, not A514. Do not overheat the plate and then call it still Grade P. The fabricator owns the WPS. SHH STEEL can share mill heat data for that review.

Usual delivery from SHH STEEL for A514 Gr.P is quenched and tempered.

A514 does not supply Grade P as-rolled or normalized only. If the mill skipped quench and temper, the plate cannot be certified A514 Grade P.

If the job wants Charpy, write the temperature and joules. A514 does not automatically include impact. Extra 3.2 hold points or special NDE add time. Plan about two months when those extras are on the order.

The certificate lists ASTM A514 Grade P; heat number; heat analysis and product analysis when ordered; tensile to the thickness table; QT delivery. Certificates may be EN 10204 3.1 or EN 10204 3.2.

Usual supply range from SHH STEEL for A514 Gr.P 100 ksi QT structural plate:

• Thickness: commonly 6 mm – 150 mm (Grade P max 6 in)
• Width: 1500 mm – 4000 mm
• Length: 3000 mm – 12000 mm

Grade B, Grade F, Grade H and Grade S cannot cover this full band. Grade Q and Grade E are the other 150 mm choices when the file names those chemistries. Browse more sizes on the products index.

Dimensional limits for ASTM A514 Grade P follow ASTM A6 / ASME SA-6 unless the purchase order names another table.

Typical thickness tolerance idea for A514 Gr.P (A6 / SA-6 reference)

Width on 1500–4000 mm plate is commonly held to about ±20–25 mm unless a tighter extra is named. Length on 3000–12000 mm plate is commonly held to about +50 / 0 mm or ±25 mm by mill practice. Flatness follows A6 / SA-6 unless a tighter class is written. SHH STEEL will not assume a zero-minus extra on A514GRP unless the order says so.

A514 Grade P already defines chemistry, QT and the thickness-dependent 100/90 ksi table. Extra items still have to be written on the purchase order.

Book name. Write ASTM A514 Grade P. If the inquiry said SA514, state on the PO that the mill will certify A514.

Product analysis. Write it if the file needs the second chemistry column.

Charpy details. Write temperature, joules, location and orientation.

Through-thickness / Z-test. Name Z15, Z25 or Z35 when needed.

NDE. A6 ultrasonic extras as named.

Hardness. The book already gives 235–293 HBW on plate to 20 mm.

Identification and stamping. Heat number, A514 Grade P, thickness and mill logo.

Third-party witness. EN 10204 3.2 with SGS, TÜV, BV, ABS, CCS, DNV or the inspector named.

A514 Grade P is the plate for a file that wants 100 ksi QT structural plate up to 150 mm with Ni-Cr-Mo-B chemistry. It is the wrong plate for a pressure vessel that names SA-517. That work sits on ASTM A517 Grade P. It is the wrong plate for ordinary carbon frames. That work sits on ASTM A36 steel plate or structural steel plates.

SHH STEEL sources ASTM A514 Grade P from first-line Chinese mills and ships it on worldwide terms. Partner mills include Wuyang (Wugang), Angang, Shougang, Hanye, Anyang Iron & Steel, Baosteel, Xinyu, Xingcheng, Yongjin, Tsingshan, TISCO (Taiyuan), Jiuquan (JISCO), Lianzhong, Zhangpu and Baoxin, plus other qualified mills when the size or QT route requires it.

Mill test certificates are issued to EN 10204 3.1 as standard. EN 10204 3.2 is arranged when the order names a third-party hold point.

Usual stock and rolling thickness: 8 mm, 10 mm, 12 mm, 16 mm, 20 mm, 25 mm, 32 mm, 40 mm, 50 mm, 60 mm, 80 mm, 100 mm, 120 mm, 150 mm.

Processing: CNC or flame cutting, bevel, flattening, UT to the named class.

Trade terms: FOB Shanghai main, CIF destination available. Payment: TT, LC, or TT + LC.

Ocean time from Shanghai: US West 14–18 days; US Gulf 28–35 days; Rotterdam / Antwerp 28–35 days; Jebel Ali 18–25 days; Singapore 7–12 days; other ports quoted.

Third-party: SGS, TÜV, BV, ABS, CCS, GL, VL, DNV, RINA, NK, KR, or the inspector named.

SHH STEEL is a global steel mill sourcing partner with mill partnerships in China. We supply ASTM, ASME, EN, DIN, JIS and GB steel to buyers in the United States, Europe, the Middle East, Southeast Asia, Africa and South America. Origin is mill-direct, China origin.

SHH STEEL has supplied steel plates to the USA, Mexico, Argentina, Peru, El Salvador, Spain, Netherlands, Germany, UAE, Saudi Arabia, South Africa, India, Thailand, Singapore, Vietnam, the Philippines, Japan and Korea.

Typical lead time: ex-stock 5–7 days; standard rolling / QT about 45–60 days; 3.2 inspection about 2 months.

Experience on this grade is simple: print A514 Grade P, keep the 150 mm Ni-Cr-Mo-B window, print product analysis when ordered, and do not invent SA-514. SHH STEEL as a global steel mill sourcing partner and steel manufacturer & exporter (mill-direct, China origin) prices A514GRP from first-line mills, reports Ni-Cr-Mo-B chemistry, records the 100/90 ksi thickness table, and issues 3.1 as standard or 3.2 when specified.

We keep the book on the order. A514GRP is not Grade Q just because both go to 150 mm. A514 Grade P is not Grade F at 80 mm. A514 Grade P is not ASTM A517 Grade P. A514 Grade P is not GB/T 16270 Q690E unless both books are met. If the drawing says Grade Q chemistry, we will not ship Grade P and call 100 ksi enough.

ASTM A514 Grade P Steel Plate is quenched-and-tempered 100 ksi structural plate to 150 mm, with 690 MPa yield to 65 mm and 620 MPa yield over 65 mm. Whether the inquiry says ASTM A514 Grade P, A514 Gr.P, A514GRP, A514-P, T-1 Grade P, SA514 Gr.P or Q690E, SHH STEEL as a global steel mill sourcing partner and steel manufacturer & exporter (mill-direct, China origin) supplies plate with Grade P chemistry, heat and product analysis as ordered, the A514 thickness table, recorded QT delivery, and EN 10204 3.1 or 3.2 certification.

SHH STEEL supplies ASTM A514 Grade P / A514 Gr.P 100ksi QT Structural Plate to the USA, Mexico, South America, Europe, the Middle East, Africa and Asia for work that actually names this grade.
