ASTM A514 Grade C Steel Plate | A514 Gr.C 100ksi QT Structural Plate supplier

ASTM A514 Grade C, also searched as A514 Gr.C, A514GRC, A514-C, A514C and 100 ksi QT plate, is a historical grade from earlier editions of ASTM A514/A514M. Older tables listed Grade C with a maximum thickness of 1¼ in / 32 mm. Current A514/A514M-18 / -22 Table 1 lists only A, B, E, F, H, P, Q and S. Grade C is not on that current table.

A purchase order that still writes Grade C is usually an old drawing. SHH STEEL will not silently recertify it as Grade B or Grade S. We confirm whether the file needs the historical Mn-Mo-B chemistry or a current sister grade.

There is no ASME SA-514. Code quenched-and-tempered vessel plate is ASTM A517 Grade B only if that vessel book still names Grade B for the Code year. Do not treat A514 Grade C as A517. ASTM A517 does not have grade C.

This page is not current Grade B. Grade B is still in Table 1 and uses Cr-Mo-V-Ti. This page is not current Grade S. Grade S is still in Table 1 and goes to 65 mm. This page is not A572 Gr.50. This page is not EN 10025-6 S690QL. This page is not GB/T 16270 Q690E.

On the old table, yield to 32 mm is 100 ksi / 690 MPa min and tensile is 110–130 ksi / 760–895 MPa. Delivery is quenched and tempered. General requirements follow A6 / SA-6.

SHH STEEL is a global steel mill sourcing partner and steel manufacturer & exporter (mill-direct, China origin). We source historical Grade C when the order writes it, print heat and product analysis, and record QT on the certificate.

Related category pages: structural steel plates, ASTM A572 / A572M and EN 10025-6.

Old-table Grade C is a high-manganese Mo-B grade with no nickel and no chromium. Values below follow earlier A514 chemistry tables. Current Table 1 does not reprint this column.

Heat Analysis and Product Analysis — historical ASTM A514 Grade C

Current Grade B uses 0.70–1.00% Mn plus Cr-V-Ti. Current Grade S uses 1.10–1.50% Mn plus Nb and goes to 65 mm. Do not stamp Grade C chemistry as Grade B unless the purchase order allows the swap. If product analysis is ordered, SHH STEEL prints both columns. Density is 7.85 g/cm³.

Tensile, Yield and Hardness — historical ASTM A514 Grade C

The old table did not give Grade C a 65–150 mm row. An 80 mm inquiry named Grade C cannot be certified as historical Grade C.

Historical Grade C has no official current twin.

In the United States the current official names are A, B, E, F, H, P, Q and S. Grade C is a search name from earlier books. ASTM A517 vessel grades are not A514.

In Europe compare EN 10025-6 S690Q or EN 10025-6 S690QL. See EN 10025-6.

In China compare GB/T 16270 Q690D / Q690E. GB/T 1591 Q690E is a different book. Neither copies historical Grade C chemistry.

Buyers pick A514 Gr.C when an old boom, trailer or mining drawing still prints Grade C. Search phrases such as A514GRC, A514 Grade C and A514-C all point here.

SHH STEEL will ask two questions before rolling: does the file need the historical Mn-Mo-B heat, or can it move to current Grade B or Grade S? We will not invent a current Table 1 stamp that says Grade C.

Treat historical Grade C as 100 ksi QT production welding. Qualify to the structural code on the job. A WPS written for current Grade B is not automatically Grade C. The fabricator owns the WPS. SHH STEEL can share mill heat data.

Usual delivery from SHH STEEL is quenched and tempered. As-rolled plate cannot be A514 Grade C.

The certificate lists ASTM A514 Grade C as a historical grade when that is what the order writes; heat number; heat analysis and product analysis when ordered; tensile to the 32 mm table; QT delivery. Certificates may be EN 10204 3.1 or EN 10204 3.2. The quote will also state that current Table 1 does not list Grade C.

Usual supply range from SHH STEEL for historical A514 Gr.C:

• Thickness: commonly 6 mm – 32 mm (old-table max 1¼ in)
• Width: 1500 mm – 4000 mm
• Length: 3000 mm – 12000 mm

Do not order Grade C for 50 mm or 80 mm. Browse more sizes on the products index.

Dimensional limits follow ASTM A6 / SA-6 unless the purchase order names another table.

Typical thickness tolerance idea for A514 Gr.C (A6 / SA-6 reference)

SHH STEEL will not assume a zero-minus extra on A514GRC unless the order says so.

Write the book year if the file depends on an old A514 edition. Write product analysis if the second chemistry column is needed. Write Charpy, Z-test, UT and 3.2 as required. Stamp heat number, A514 Grade C and thickness.

SHH STEEL sources historical ASTM A514 Grade C from first-line Chinese mills when the order writes that chemistry. Partner mills include Wuyang (Wugang), Angang, Shougang, Hanye, Anyang Iron & Steel, Baosteel, Xinyu, Xingcheng, TISCO (Taiyuan), Jiuquan (JISCO) and other qualified mills.

Mill test certificates are EN 10204 3.1 as standard, 3.2 when named. Usual thickness: 6–32 mm. Processing: cutting, bevel, flattening, UT. Trade terms: FOB Shanghai, CIF available. Payment: TT, LC, or TT + LC. Ocean time: US West 14–18 days; US Gulf 28–35 days; Rotterdam 28–35 days; Jebel Ali 18–25 days; Singapore 7–12 days. Third-party: SGS, TÜV, BV, ABS, CCS, DNV or the inspector named.

SHH STEEL is a global steel mill sourcing partner with mill partnerships in China. We supply ASTM, ASME, EN, DIN, JIS and GB steel to the United States, Europe, the Middle East, Southeast Asia, Africa and South America. Origin is mill-direct, China origin.

Typical lead time: ex-stock 5–7 days; standard rolling / QT about 45–60 days; 3.2 about 2 months.

Experience on this grade is simple: say it is historical, keep the 32 mm cap, and do not pretend current Table 1 still lists Grade C. SHH STEEL as a global steel mill sourcing partner and steel manufacturer & exporter (mill-direct, China origin) will either roll the old chemistry or offer current Grade B / Grade S when the purchase order allows the move.

ASTM A514 Grade C Steel Plate is a historical 100 ksi QT structural grade from earlier A514 tables, limited to 32 mm. Current A514/A514M Table 1 does not list Grade C. Whether the inquiry says ASTM A514 Grade C, A514 Gr.C, A514GRC or A514-C, SHH STEEL as a global steel mill sourcing partner and steel manufacturer & exporter (mill-direct, China origin) will confirm the old chemistry, print heat and product analysis as ordered, record QT delivery, and issue EN 10204 3.1 or 3.2.

SHH STEEL supplies historical ASTM A514 Grade C / A514 Gr.C 100ksi QT Structural Plate for replacement and legacy files that still name this grade.

Contact SHH STEEL for mill rolling, a current-grade alternative, cutting, bevel, 3.2 inspection or a worldwide quotation.
