EN 10025-4 S460M Steel Plate | S460M Fine Grain Structural Steel

EN 10025-4 S460M is a thermomechanically rolled fine-grain structural steel plate with a minimum yield strength of 460 MPa and impact tested at –20°C. It offers high strength, good weldability and toughness for heavy structural applications. SHH STEEL is a China Mill-Direct Exporter supplying S460M steel plate
Equivalent Grades:
ASTM A572 Gr 65 (TMCP ref) / JIS SM570 / GB Q460MD / ISO E460M
Material Specification:
EN 10025-4 — Delivery: Thermo-Mechanically Rolled (TMCP), -20℃ impact guaranteed
Share:
General Description
Material Specification
Chemical Composition
Mechanical Properties
Delivery Conditions
Tolerances
Weldability
Equivalent Material Grades
Applications
Why Choose SHH STEEL
FAQ
Conclusion

What is EN 10025-4 S460M Steel Plate?

General Description

As a professional steel plate supplier and China Mill-Direct Exporter, SHH STEEL is pleased to present EN 10025-4 S460M Steel Plate (Material Number: 1.8827).

S460M is a thermomechanically rolled (TMCP) weldable fine-grain structural steel under the European standard EN 10025-4. It provides a minimum yield strength of 460 MPa (for thickness ≤ 16 mm) and is impact tested at –20°C with a minimum energy of 40 J. This is one of the highest strength grades in the EN 10025-4 series, offering excellent combination of strength, toughness and weldability for heavily loaded structures. SHH STEEL sources this material directly from leading Chinese steel mills, ensuring competitive mill-direct pricing, stable quality and reliable delivery.

We supply S460M steel plate in thicknesses from 6 mm to 120 mm (thicker plates available on request), widths up to 3000–4000 mm, and lengths up to 12000–18000 mm. Custom cutting, shot blasting and priming services are available. All plates are delivered with full Mill Test Certificates (EN 10204 3.1).

Material Specification

EN 10025-4 S460M steel plate is produced in accordance with EN 10025-4.

Specification Element Requirement SHH STEEL Compliance
Primary Standard EN 10025-4 Full compliance
Steel Grade S460M (1.8827) Confirmed
Delivery Condition Thermomechanically rolled (M) Confirmed
Product Form Steel Plate Available
Thickness Range 6 mm – 120 mm Custom sizes available
Width / Length Up to 3000–4000 mm / 12000–18000 mm Custom cutting supported
Certification EN 10204 3.1 / 3.2 Available

Chemical Composition

According to EN 10025-4, the chemical composition is specified for both ladle analysis (cast analysis) and product analysis.

Ladle Analysis (Cast Analysis)

Element Max. / Range (%)
Carbon (C) ≤ 0.16
Silicon (Si) ≤ 0.60
Manganese (Mn) ≤ 1.70
Phosphorus (P) ≤ 0.030
Sulfur (S) ≤ 0.025
Niobium (Nb) ≤ 0.05
Vanadium (V) ≤ 0.12
Aluminium (Al total) ≥ 0.020
Titanium (Ti) ≤ 0.05
Chromium (Cr) ≤ 0.30
Nickel (Ni) ≤ 0.80
Molybdenum (Mo) ≤ 0.20
Copper (Cu) ≤ 0.55
Nitrogen (N) ≤ 0.025

Product Analysis

Element Max. / Range (%)
Carbon (C) ≤ 0.18
Silicon (Si) ≤ 0.65
Manganese (Mn) ≤ 1.80
Phosphorus (P) ≤ 0.035
Sulfur (S) ≤ 0.030
Niobium (Nb) ≤ 0.06
Vanadium (V) ≤ 0.14
Aluminium (Al total) ≥ 0.015
Titanium (Ti) ≤ 0.06
Chromium (Cr) ≤ 0.35
Nickel (Ni) ≤ 0.85
Molybdenum (Mo) ≤ 0.23
Copper (Cu) ≤ 0.60
Nitrogen (N) ≤ 0.027

Note:

  • The minimum Al content does not apply if sufficient other nitrogen-binding elements are present.
  • Carbon Equivalent (CEV) is controlled to ensure good weldability.

Mechanical Properties

Mechanical properties of EN 10025-4 S460M (longitudinal direction):

Thickness (mm) Yield Strength ReH (min) Tensile Strength Rm Elongation A (min) Impact Energy KV (min)
≤ 16 460 MPa 540 – 720 MPa 17% 40 J at –20°C
> 16 ≤ 40 440 MPa 540 – 720 MPa 17% 40 J at –20°C
> 40 ≤ 63 430 MPa 530 – 710 MPa 17% 40 J at –20°C
> 63 ≤ 80 410 MPa 510 – 690 MPa 17% 40 J at –20°C
> 80 ≤ 100 400 MPa 500 – 680 MPa 17% 40 J at –20°C
> 100 ≤ 120 385 MPa 490 – 660 MPa 17% 40 J at –20°C

Density: 7.85 g/cm³

Delivery Conditions

SHH STEEL, as a China Mill-Direct Supplier, supplies EN 10025-4 S460M steel plate in the thermomechanically rolled (M) condition.

Additional options:

  • Shot blasting and shop primer
  • Ultrasonic testing (EN 10160)
  • Z-direction testing (Z15 / Z25 / Z35)
  • Third-party inspection (SGS, BV, TUV, etc.)

Tolerances

Dimensional tolerances for S460M steel plate follow EN 10029 (for plates).

  • Thickness, width and length tolerances according to the ordered class.
  • Flatness according to EN 10029.
  • Edge conditions: Mill edge or cut edge (flame / plasma).

Tighter tolerances can be provided upon request.

Weldability

S460M has moderate-to-good weldability for a high-strength thermomechanically rolled fine-grain steel. It can be welded by conventional methods (SMAW, GMAW, FCAW, SAW).

Recommended welding consumables:

Welding Process Recommended Consumables
SMAW (Stick) E8018, E7018
GMAW (MIG/MAG) ER80S-D2, ER70S-6
FCAW E81T1, E71T-1
SAW EH14 / EM12K + suitable flux

Preheating is generally required for thicker plates. Low-hydrogen consumables and strict control of heat input are strongly recommended.

Equivalent Material Grades

Grade Standard Notes
S460M EN 10025-4 —
1.8827 EN Material number
Q460M / Q460MD GB/T 1591 Closest Chinese equivalents
A572 Grade 65 (approx.) ASTM Similar strength level
StE 460 TM DIN (old) Former designation

Applications

EN 10025-4 S460M is used in structural applications requiring very high strength. Typical uses include:

Application Area Typical Components / Uses (Keywords)
Building Structures Heavy beams, columns, high-load frames – S460M Structural Steel
Bridges Bridge components – S460M Bridge
Machinery Heavy equipment frames – S460M Machinery
Construction High-strength construction – S460M Construction
Offshore & Industrial Heavy structural components – S460M Industrial
General Fabrication High-strength fine-grain structures – S460M Fabrication

Why Choose SHH STEEL

SHH STEEL is a China Mill-Direct Exporter. We maintain long-term strategic cooperation with major Chinese steel mills and act as a first-level (primary) agent. This direct mill supply model allows us to offer competitive mill-direct pricing, faster delivery times, stable and traceable quality, and full Mill Test Certificates (EN 10204 3.1 / 3.2) for EN 10025-4 S460M Steel Plate.

Customers benefit from reliable supply, short lead times and cost-effective solutions for high-strength thermomechanically rolled fine-grain structural steel projects worldwide. Our professional export team provides technical support and customized processing services to meet project requirements.

FAQ

What does the “M” in S460M mean?
“M” indicates that the steel is supplied in the thermomechanically rolled condition and meets impact requirements of minimum 40 J at –20°C.
What is the difference between S460M and S460ML?
Both are thermomechanically rolled. S460M is impact tested at –20°C (40 J), while S460ML is impact tested at –50°C (27 J), offering better low-temperature toughness.
Is S460M suitable for heavily loaded structures?
Yes. With a minimum yield strength of 460 MPa, S460M is one of the highest strength thermomechanically rolled fine-grain grades under EN 10025-4.

Conclusion

EN 10025-4 S460M (1.8827) Steel Plate from SHH STEEL is a high-strength thermomechanically rolled fine-grain structural steel offering 460 MPa yield strength and reliable toughness at –20°C. As a China Mill-Direct Exporter, we provide competitive pricing, fast delivery and consistent quality backed by full mill certifications. Trust SHH STEEL for your S460M fine grain structural steel plate requirements.

Contact SHH STEEL today for stock availability, pricing and technical support. EN 10025-4 S460M Steel Plate, S460M steel plate, S460M fine grain structural steel, EN 10025 S460M, S460M equivalent, S460M supplier, 1.8827
