EN 10025-2 S185 Steel Plate | S185 Structural Steel
What is EN 10025-2 S185 Steel Plate?
As a professional steel plate supplier and China Mill-Direct Exporter, SHH STEEL is pleased to present EN 10025-2 S185 Steel Plate (Material Number: 1.0035).
S185 is the lowest strength grade of non-alloy structural steel under the European standard EN 10025-2. It provides a minimum yield strength of 185 MPa (for thickness ≤ 16 mm) and is characterized by excellent weldability, formability and cost-effectiveness. This grade is typically used for light structural applications, general fabrication and components where high strength is not required. SHH STEEL sources this material directly from leading Chinese steel mills, ensuring competitive mill-direct pricing, stable quality and reliable delivery.
We supply S185 steel plate in thicknesses from 6 mm to 150 mm (thicker plates available on request), widths up to 3000–4000 mm, and lengths up to 12000–18000 mm. Custom cutting, shot blasting and priming services are available. All plates are delivered with full Mill Test Certificates (EN 10204 3.1).
Material Specification
EN 10025-2 S185 steel plate is produced in accordance with EN 10025-2.
| Specification Element | Requirement | SHH STEEL Compliance |
|---|---|---|
| Primary Standard | EN 10025-2 | Full compliance |
| Steel Grade | S185 (1.0035) | Confirmed |
| Delivery Condition | +AR (As-rolled) | Available |
| Product Form | Steel Plate | Available |
| Thickness Range | 6 mm – 150 mm | Custom sizes available |
| Width / Length | Up to 3000–4000 mm / 12000–18000 mm | Custom cutting supported |
| Certification | EN 10204 3.1 / 3.2 | Available |
Chemical Composition
According to EN 10025-2, S185 has relatively loose chemical composition requirements (mainly limits on impurities).
Ladle Analysis (Cast Analysis)
| Element | Max. Limit (%) |
|---|---|
| Phosphorus (P) | 0.045 |
| Sulfur (S) | 0.045 |
| Nitrogen (N) | 0.012 |
| Copper (Cu) | 0.55 |
Product Analysis
| Element | Max. Limit (%) |
|---|---|
| Phosphorus (P) | 0.055 |
| Sulfur (S) | 0.055 |
| Nitrogen (N) | 0.014 |
| Copper (Cu) | 0.60 |
Note:
- Carbon, Silicon and Manganese contents are not strictly limited in the standard for S185.
- The maximum nitrogen content does not apply if the total aluminium content is ≥ 0.020%.
- Deoxidation method is at the manufacturer’s discretion.
Mechanical Properties
Mechanical properties of EN 10025-2 S185 (typical values):
| Thickness (mm) | Yield Strength ReH (min) | Tensile Strength Rm | Elongation A (min) |
|---|---|---|---|
| ≤ 16 | 185 MPa | 290 – 510 MPa | 18% |
| > 16 ≤ 40 | 175 MPa | 290 – 510 MPa | 18% |
| > 40 ≤ 63 | 175 MPa | 290 – 510 MPa | 17% |
| > 63 ≤ 100 | 175 MPa | 290 – 510 MPa | 16% |
| > 100 ≤ 150 | 165 MPa | 280 – 500 MPa | 15% |
Density: 7.85 g/cm³
Note: Impact testing is not mandatory for S185 under EN 10025-2.
Delivery Conditions
SHH STEEL, as a China Mill-Direct Supplier, supplies EN 10025-2 S185 steel plate mainly in the as-rolled (+AR) condition.
Additional options:
- Shot blasting and shop primer
- Ultrasonic testing (EN 10160)
- Third-party inspection (SGS, BV, TUV, etc.)
Tolerances
Dimensional tolerances for S185 steel plate follow EN 10029 (for plates) or EN 10051 (for strips).
- Thickness, width and length tolerances according to the ordered class.
- Flatness according to EN 10029.
- Edge conditions: Mill edge or cut edge (flame / plasma).
Tighter tolerances can be provided upon request.
Weldability
S185 has excellent weldability due to its low strength and low carbon content. It can be welded by all conventional methods (SMAW, SAW, GMAW, FCAW, etc.) without preheating in most cases. It is one of the easiest structural steels to weld and form.
Equivalent Material Grades
| Grade | Standard | Notes |
|---|---|---|
| S185 | EN 10025-2 | — |
| 1.0035 | EN | Material number |
| Q195 | GB/T 700 | Closest Chinese equivalent |
| A283 Grade A/B | ASTM | Approximate |
| St33 | DIN (old) | Former designation |
| Fe310 | ISO | Approximate |
Applications
EN 10025-2 S185 is used for light structural and general fabrication applications where high strength is not required. Typical uses include:
| Application Area | Typical Components / Uses (Keywords) |
|---|---|
| Light Structures | Light frames, supports – S185 Structural Steel |
| General Fabrication | Simple welded structures – S185 Fabrication |
| Machinery | Non-critical base plates and frames – S185 Machinery |
| Construction | Light construction components – S185 Construction |
| Storage | Simple tanks and silos – S185 Storage |
| Agricultural Equipment | Light equipment frames – S185 Agricultural |
Why Choose SHH STEEL
SHH STEEL is a China Mill-Direct Exporter. We maintain long-term strategic cooperation with major Chinese steel mills and act as a first-level (primary) agent. This direct mill supply model allows us to offer competitive mill-direct pricing, faster delivery times, stable and traceable quality, and full Mill Test Certificates (EN 10204 3.1 / 3.2) for EN 10025-2 S185 Steel Plate.
Customers benefit from reliable supply, short lead times and cost-effective solutions for structural steel projects worldwide. Our professional export team provides technical support and customized processing services to meet project requirements.
FAQ
- What is the main characteristic of S185?S185 is the lowest strength grade in the EN 10025-2 series, with a minimum yield strength of 185 MPa. It offers excellent weldability and formability at a low cost.
- Does S185 require impact testing?No. Impact testing is not mandatory for S185 under EN 10025-2 (unlike JR, J0 and J2 grades).
- What is the closest Chinese equivalent to S185?Q195 (GB/T 700).
Conclusion
EN 10025-2 S185 (1.0035) Steel Plate from SHH STEEL is an economical low-strength non-alloy structural steel ideal for light fabrication and general applications. As a China Mill-Direct Exporter, we provide competitive pricing, fast delivery and consistent quality backed by full mill certifications. Trust SHH STEEL for your S185 structural steel plate requirements.
Contact SHH STEEL today for stock availability, pricing and technical support. EN 10025-2 S185 Steel Plate, S185 steel plate, S185 structural steel, EN 10025 S185, S185 equivalent, S185 supplier, 1.0035
