EN 10025-2 S355JR Steel Plate | S355JR Structural Steel
What is EN 10025-2 S355JR Steel Plate?
As a professional steel plate supplier and China Mill-Direct Exporter, SHH STEEL is pleased to present EN 10025-2 S355JR Steel Plate (Material Number: 1.0045).
S355JR is one of the most popular high-strength non-alloy structural steels under the European standard EN 10025-2. It provides a minimum yield strength of 355 MPa (for thickness ≤ 16 mm) combined with good weldability, formability and toughness. The “JR” designation indicates that the material meets impact requirements of 27 J at +20°C. SHH STEEL sources this material directly from leading Chinese steel mills, ensuring competitive mill-direct pricing, stable quality and reliable delivery.
We supply S355JR steel plate in thicknesses from 6 mm to 150 mm (thicker plates available on request), widths up to 3000–4000 mm, and lengths up to 12000–18000 mm. Custom cutting, shot blasting and priming services are available. All plates are delivered with full Mill Test Certificates (EN 10204 3.1).
Material Specification
EN 10025-2 S355JR steel plate is produced in accordance with EN 10025-2.
| Specification Element | Requirement | SHH STEEL Compliance |
|---|---|---|
| Primary Standard | EN 10025-2 | Full compliance |
| Steel Grade | S355JR (1.0045) | Confirmed |
| Delivery Condition | +AR (As-rolled) or +N (Normalized) | Available |
| Product Form | Steel Plate | Available |
| Thickness Range | 6 mm – 150 mm | Custom sizes available |
| Width / Length | Up to 3000–4000 mm / 12000–18000 mm | Custom cutting supported |
| Certification | EN 10204 3.1 / 3.2 | Available |
Chemical Composition
According to EN 10025-2, the chemical composition is specified for both ladle analysis (cast analysis) and product analysis.
Ladle Analysis (Cast Analysis)
| Element | Max. Limit (%) |
|---|---|
| Carbon (C) | 0.24 |
| Silicon (Si) | 0.55 |
| Manganese (Mn) | 1.60 |
| Phosphorus (P) | 0.035 |
| Sulfur (S) | 0.035 |
| Nitrogen (N) | 0.012 |
| Copper (Cu) | 0.55 |
Product Analysis
| Element | Max. Limit (%) |
|---|---|
| Carbon (C) | 0.27 |
| Silicon (Si) | 0.60 |
| Manganese (Mn) | 1.70 |
| Phosphorus (P) | 0.045 |
| Sulfur (S) | 0.045 |
| Nitrogen (N) | 0.014 |
| Copper (Cu) | 0.60 |
Note:
- The maximum nitrogen content does not apply if the total aluminium content is ≥ 0.020%.
- Carbon Equivalent (CEV) is controlled to ensure good weldability.
Mechanical Properties
Mechanical properties of EN 10025-2 S355JR (longitudinal direction):
| Thickness (mm) | Yield Strength ReH (min) | Tensile Strength Rm | Elongation A (min) | Impact Energy KV (min) |
|---|---|---|---|---|
| ≤ 16 | 355 MPa | 470 – 630 MPa | 22% | 27 J at +20°C |
| > 16 ≤ 40 | 345 MPa | 470 – 630 MPa | 22% | 27 J at +20°C |
| > 40 ≤ 63 | 335 MPa | 470 – 630 MPa | 21% | 27 J at +20°C |
| > 63 ≤ 100 | 325 MPa | 470 – 630 MPa | 20% | 27 J at +20°C |
| > 100 ≤ 150 | 295 – 285 MPa | 450 – 600 MPa | 18% | 27 J at +20°C |
Delivery Conditions
SHH STEEL, as a China Mill-Direct Supplier, supplies EN 10025-2 S355JR steel plate mainly in the following conditions:
- +AR (As-rolled) – most common
- +N (Normalized) – available on request
Additional options:
- Shot blasting and shop primer
- Ultrasonic testing (EN 10160)
- Z-direction testing (Z15 / Z25 / Z35)
- Third-party inspection (SGS, BV, TUV, etc.)
Tolerances
Dimensional tolerances for S355JR steel plate follow EN 10029 (for plates) or EN 10051 (for strips).
- Thickness, width and length tolerances according to the ordered class.
- Flatness according to EN 10029.
- Edge conditions: Mill edge or cut edge (flame / plasma).
Tighter tolerances can be provided upon request.
Weldability
S355JR has good weldability. It can be welded by conventional methods (SMAW, SAW, GMAW, FCAW, etc.). Due to the higher strength and carbon equivalent compared with S235/S275 grades, preheating is often recommended for thicker plates. Low-hydrogen consumables are advised for critical applications.
Equivalent Material Grades
| Grade | Standard | Notes |
|---|---|---|
| S355JR | EN 10025-2 | — |
| 1.0045 | EN | Material number |
| Q355B | GB/T 1591 | Closest Chinese equivalent |
| A572 Grade 50 | ASTM | Approximate |
| St52-3 | DIN (old) | Former designation |
Applications
EN 10025-2 S355JR is widely used in structural applications requiring higher strength. Typical uses include:
| Application Area | Typical Components / Uses (Keywords) |
|---|---|
| Building Structures | Beams, columns, heavy frames – S355JR Structural Steel |
| Bridges | Bridge components – S355JR Bridge |
| Machinery | Heavy equipment frames, base plates – S355JR Machinery |
| Construction | High-strength construction steel – S355JR Construction |
| Offshore & Industrial | Structural components – S355JR Industrial |
| General Fabrication | Welded high-strength structures – S355JR Fabrication |
Why Choose SHH STEEL
SHH STEEL is a China Mill-Direct Exporter. We maintain long-term strategic cooperation with major Chinese steel mills and act as a first-level (primary) agent. This direct mill supply model allows us to offer competitive mill-direct pricing, faster delivery times, stable and traceable quality, and full Mill Test Certificates (EN 10204 3.1 / 3.2) for EN 10025-2 S355JR Steel Plate.
Customers benefit from reliable supply, short lead times and cost-effective solutions for structural steel projects worldwide. Our professional export team provides technical support and customized processing services to meet project requirements.
FAQ
- What does the “JR” in S355JR mean?“JR” indicates that the steel meets the impact energy requirement of minimum 27 J at +20°C.
- What is the difference between S275JR and S355JR?S355JR has a significantly higher minimum yield strength (355 MPa vs 275 MPa) and higher tensile strength, making it suitable for more heavily loaded structural applications.
- Can SHH STEEL supply normalized S355JR (+N)?Yes. Both as-rolled (+AR) and normalized (+N) conditions are available.
Conclusion
EN 10025-2 S355JR (1.0045) Steel Plate from SHH STEEL is a high-strength non-alloy structural steel widely used in construction, bridges and heavy engineering. As a China Mill-Direct Exporter, we provide competitive pricing, fast delivery and consistent quality backed by full mill certifications. Trust SHH STEEL for your S355JR structural steel plate requirements.
Contact SHH STEEL today for stock availability, pricing and technical support.
EN 10025-2 S355JR Steel Plate, S355JR steel plate, S355JR structural steel, EN 10025 S355JR, S355JR equivalent, S355JR supplier, 1.0045
