When it comes to building tough ships and offshore platforms that can handle freezing cold and heavy loads, BV Grade FH36 steel plate is a top pick.
This high-strength steel is made for extreme marine conditions, offering great toughness in super cold weather, easy welding, and good resistance to rust from saltwater. It’s part of the “FH” family, which means it’s built for high performance in freezing temps.
At SHH STEEL, we make and send out BV FH36 plates that follow strict Bureau Veritas (BV) rules. These plates are often used in ship hulls, decks, and other parts for vessels in polar areas.
What makes BV Grade FH36 special? It keeps its strength even at -60°C, helping ships stay safe and last longer in icy seas. If you’re in shipbuilding or engineering, knowing about BV FH36 steel plate can help you choose the right material for your project.
BV Grade FH36 is classified as a high-strength steel under BV rules, in the “FH” group for better tensile and extreme cold toughness.
It’s usually hot-rolled and can use thermo-mechanical controlled processing (TMCP) to get a fine structure that boosts its qualities. It follows BV Rules for the Classification of Steel Ships, perfect for ships in very cold waters.
At SHH STEEL, every BV FH36 plate is certified and ready for worldwide use.
We offer BV FH36 steel plates in different sizes for ship projects in cold areas. This range helps with custom builds and cuts down waste.
Here’s a quick table summary:
| Dimension Type | Range/Details |
| Thickness | 5 mm to 100 mm |
| Width | Up to 3000 mm |
| Length | Up to 12000 mm |
| Custom Options | Available for cuts and shapes |
Need exact sizes for your BV/FH36 plates? Our experts can tailor them to your designs.
The mix in BV FH36 steel plate is set for strength and cold resistance.
Elements are controlled to skip problems like breaking or bad welds. Low phosphorus and sulfur stop cracks.
BV sets limits by ladle (melt) analysis and product (final) checks. Here’s the usual setup:
At SHH STEEL, we test batches to match specs for trusty BV FH36 marine grade steel.
| Element | Ladle Analysis (Max % unless range) | Product Analysis (Max % unless range) |
| Carbon (C) | ≤ 0.16 | ≤ 0.18 |
| Manganese (Mn) | 0.90 – 1.60 | 0.85 – 1.65 |
| Silicon (Si) | ≤ 0.50 | ≤ 0.55 |
| Phosphorus (P) | ≤ 0.025 | ≤ 0.030 |
| Sulfur (S) | ≤ 0.025 | ≤ 0.030 |
| Aluminum (Al) | ≥ 0.015 (acid soluble) | ≥ 0.010 |
| Niobium (Nb) | 0.02 – 0.05 | 0.02 – 0.05 |
| Vanadium (V) | 0.05 – 0.10 | 0.05 – 0.10 |
Note: Traces like copper or chromium may add for better rust fight.
BV FH36 steel plate has strong features for heavy loads in freezing ship work.
It has high yield to fight bending, solid tensile for lasting power, and good stretch for shaping without snaps.
It also passes impact tests at -60°C for tough in ice-cold. These help BV Grade FH36 handle waves, bumps, and wear in polar.
See the table for key properties:
| Property | Value/Requirement |
| Yield Strength (min) | 355 MPa |
| Tensile Strength | 490 – 630 MPa |
| Elongation (min) | 21% (in 200 mm) |
| Charpy V-Notch Impact | 34 J (longitudinal) at -60°C |
Vs. basic steels, BV/FH36 gives top performance for cold marine jobs.
At SHH STEEL, we deliver BV FH36 steel plates ready for your needs.
Main states: normalized rolling (heat to 900°C, air cool) for better toughness.
For thick plates, thermo-mechanical controlled processing (TMCP) mixes rolling and cooling for strength without weld loss.
Plates include BV cert, with MTC per EN 10204 3.1 or 3.2, proving spec match.
Packed with waterproof and wood crates.
Times 15-30 days, rush options. Global shipping.
Special needs? Tell us early.
| Delivery Condition | Description |
| Normalized | Heated and air-cooled for uniformity |
| TMCP | Controlled rolling and cooling for enhanced strength |
China’s steel prices for BV FH36 vary by raw costs and demand.
Now, expect $550-$750 per ton for standard. Thin lower, thick higher from processing.
Trends and BV cert add 10-20%. SHH STEEL fair prices, bulk deals.
Quote for BV Grade FH36 – quality saves on fixes long-term.
Fit is key in ships for easy joins. BV FH36 from SHH STEEL follows BV/EN 10029 for sizes/flat.
Prevents warps. New gear to hit specs, inspect each.
Tighter needs? Talk to us.
Table of usual tolerances:
| Tolerance Type | Specification/Details |
| Thickness | For <25 mm: +0.3 mm / -0.3 mm; For 25-40 mm: +0.4 mm / -0.3 mm; Up for thicker |
| Width | +20 mm / -0 mm |
| Length | +50 mm / -0 mm |
| Flatness | Max 6 mm per meter |
| Squareness | Max 10 mm deviation |
Prepares BV/FH36 for exact builds.
To pick the right steel, compare BV FH36 with BV AH36, BV DH36, BV EH36, BV FH40. They differ in cold resistance and strength.
BV FH36 for extreme cold with high strength.
| Property | BV AH36 | BV DH36 | BV EH36 | BV FH40 | BV FH36 |
| Yield Strength (min MPa) | 355 | 355 | 355 | 390 | 355 |
| Tensile Strength (MPa) | 490-620 | 490-620 | 490-620 | 510-650 | 490-620 |
| Impact Test Temp (°C) | 0 | -20 | -40 | -60 | -60 |
| Toughness (Charpy J min) | 34 | 34 | 34 | 41 | 34 |
| Typical Use | High stress | Cold high | Arctic high | Extreme cold high | Extreme cold high |
| Cost Relative | Medium-High | Medium-High | High | Higher | High |
BV Grade FH36 optimal for extreme cold high-stress.
BV FH36 has world matches for sourcing.
These have like chemistry and properties, ok with approvals. Good for global builds.
SHH STEEL supplies BV FH36 or equals for your rules.
Here’s a table of common equivalents:
| Classification Society | Equivalent Grade |
| Lloyd’s Register (LR) | FH36 |
| American Bureau of Shipping (ABS) | FH36 |
| Det Norske Veritas (DNV) | NV F36 |
| Germanischer Lloyd (GL) | F36 |
| Registro Italiano Navale (RINA) | FH36 |
| China Classification Society (CCS) | FH36 |
| Nippon Kaiji Kyokai (NK) | FH36 |
| Korean Register (KR) | FH36 |
To boost performance, BV FH36 can have extras like Z-testing (Z25 or Z35) for better through-thickness strength, reducing tear risks in welds.
We also do ultrasonic checks to spot hidden flaws and fine-grain treatments for extra toughness.
For welded parts, simulated post-weld heat treatment is available. Specify these when ordering from SHH STEEL for premium shipbuilding steel.
BV FH36 steel plate is versatile in extreme cold marine work. It’s key for ship hulls that take ice hits, like in icebreakers.
In offshore setups, it builds platforms and legs that stand up to arctic waves. Other uses: barges in polar areas, ferries in icy waters, and coast wind farms in freezing spots.
Its strength and cold resistance make it ideal for long sea exposure. SHH STEEL has delivered BV Grade FH36 for many successful projects.
Pick SHH STEEL for BV FH36 steel plates because we’re pros in making and shipping them from China.
Our modern factories ensure top quality at good prices. We offer expert help from start to finish, including tech advice and fast global shipping.
With exports to 50+ countries and full BV certs, we’re reliable. Plus, we focus on green methods. Trust us for strong, dependable marine steel plate.
BV FH36 steel plate is a powerhouse in the shipbuilding world, offering unmatched strength, reliability, and value for extreme cold applications.
From its precise specifications to versatile applications, it’s clear why this marine grade is a top pick for professionals. As your dedicated SHH STEEL supplier, we’re here to provide premium BV Grade FH36 tailored to your needs. Ready to elevate your next project? Reach out today for expert advice and unbeatable service.
