ASTM A516 GR 702

ASTM A516 GR 70 is a carbon steel plate specified under the ASTM A516 standard for pressure vessels and boilers in moderate and low-temperature services. Renowned for its high strength, toughness, and weldability, this boiler quality steel plate is ideal for applications requiring resistance to corrosive environments, particularly when enhanced with NACE MR0175/ISO 15156 and HIC (Hydrogen Induced Cracking) compliance. It is widely used in industries such as oil and gas, petrochemical, and power generation, making it a top choice for pressure vessel steel plate for sour gas environments.

The ASTM A516 GR 70 specification ensures consistent quality for pressure vessel applications. Key dimensional specifications include: Thickness: 6mm to 300mm  Width: 1500mm to 4050mm Length: 3000mm to 15000mm Plates up to 40mm in thickness are typically supplied in the as-rolled condition, while those over 40mm are normalized to enhance mechanical properties. The A516 Gr 70 plate is manufactured to meet ASTM A516/A516M standards, ensuring suitability for ASTM A516 GR 70 NACE HIC steel plate for oil and gas applications.

The chemical composition of ASTM A516 GR 70 is carefully controlled to ensure optimal performance in corrosive environments. Below is the maximum allowable content for key elements:

Carbon Equivalent (Ceq): Ceq = [C + Mn/6 + (Cr + Mo + V)/5 + (Ni + Cu)/15] % The low phosphorus and sulfur content enhance weldability, making it ideal for boiler quality steel plate for petrochemical applications.

The mechanical properties of ASTM A516 GR 70 ensure its suitability for high-pressure applications:

These properties provide excellent strength and toughness, making A516 Gr 70 plate ideal for pressure vessel steel plate for sour gas environments.

The ASTM A516 GR 70 plate is versatile, serving critical applications:

Pressure Vessels: Used in high-pressure vessels for oil and gas, petrochemical, and power generation industries. Storage Tanks: Ideal for tanks storing liquefied gases or chemicals in pressure vessel steel plate for oil refineries. Boilers: Employed in steam drums and boiler components operating under high pressure. Railcars: Used in railcar tanks for transporting hazardous materials, leveraging its high strength. Offshore Platforms: Suitable for structures exposed to corrosive marine environments.

These applications highlight the plate’s role as a boiler quality steel plate for oil and gas.

ASTM A516 GR 70 aligns with several international standards, ensuring compatibility for global projects:

These equivalent grades make the boiler quality steel plate versatile for ASTM A516 GR 70 NACE HIC steel plate suppliers serving diverse markets.

The dimensional tolerances for ASTM A516 GR 70 plates comply with ASTM A20/A20M standards, ensuring precision:

Thickness Tolerance: Varies based on thickness (e.g., ±0.3mm for 6-10mm plates, ±0.8mm for 40-80mm plates). Width Tolerance: Typically ±20mm for widths up to 4050mm. Length Tolerance: Typically ±25mm for lengths up to 15000mm. Flatness: Meets ASTM A20 requirements for pressure vessel plates.

These tolerances ensure consistency for pressure vessel steel plate for oil and gas.

ASTM A516 GR 70 plates are delivered under specific conditions to meet project requirements:

As-Rolled: Plates up to 40mm are typically supplied as-rolled. Normalized: Plates over 40mm are normalized to enhance toughness and uniformity. Stress Relieved: Optional stress relief is available upon request to reduce residual stresses.

Gangsteel ensures that A516 Gr 70 plate meets these conditions, making it suitable for boiler quality steel plate for petrochemical applications.

ASTM A516 GR 70 plates are delivered under specific conditions to meet project requirements:

As-Rolled: Plates up to 40mm are typically supplied as-rolled. Normalized: Plates over 40mm are normalized to enhance toughness and uniformity. Stress Relieved: Optional stress relief is available upon request to reduce residual stresses.

Gangsteel ensures that A516 Gr 70 plate meets these conditions, making it suitable for boiler quality steel plate for petrochemical applications.

The mechanical properties of ASTM A516 GR 70 ensure its suitability for high-pressure applications:

Key Differences: Strength: A516 Gr 70 plate offers higher yield and tensile strength, ideal for high-pressure applications. Weldability: A516 Gr 60 has slightly better weldability due to lower carbon content, suitable for complex fabrications. Applications: Gr 70 is preferred for ASTM A516 GR 70 NACE HIC steel plate for petrochemical applications, while Gr 60 suits less demanding environments.

Gangsteel offers ASTM A516 GR 70 with supplementary requirements to meet stringent standards:

HIC Testing: Ensures resistance to Hydrogen Induced Cracking in sour gas environments. NACE MR0175/ISO 15156: Verifies suitability for H2S-rich environments. Additional Tests: Includes Z15, Z25, Z35 (through-thickness properties), S1 (vacuum treatment), S2 (product analysis), S3 (simulated PWHT), S4.1 (shear strength), S5 (charpy V-notch impact), S6 (drop weight), S7 (high-temperature tension), S8 (ultrasonic testing), S9 (magnetic particle), S11 (tension test), S12 (bend test), S14 (thickness tolerance), and S17 (vacuum carbon-deoxidized). Mill Test Certificate (MTC): Provided per EN 10204 3.1 or 3.2, ensuring traceability and compliance.

These tests make Gangsteel a trusted ASTM A516 GR 70 NACE HIC steel plate supplier.

Choosing ASTM A516 GR 70 offers several advantages:

High Strength: Superior tensile and yield strength for high-pressure applications. Corrosion Resistance: NACE and HIC compliance ensures performance in sour gas environments. Versatility: Wide range of thicknesses and sizes for diverse project needs. Global Standards: Meets ASTM, ASME, EN, and BS standards, ensuring compatibility. Cost-Effective: Balances high performance with competitive pricing.

Gangsteel’s A516 Gr 70 plate is backed by rigorous testing and global delivery, making it a top choice for pressure vessel steel plate for sour gas environments.

ASTM A516 GR 70 is a high-performance carbon steel plate ideal for pressure vessels, boilers, and tanks in demanding environments. Its high strength, NACE and HIC compliance, and excellent weldability make it a preferred choice for boiler quality steel plate for oil and gas. Gangsteel, as a leading ASTM A516 GR 70 NACE HIC steel plate supplier, offers customized A516 Gr 70 plate with rigorous testing and global delivery. For quotes or technical support, visit our product page or contact our team today.
